APPSeCONNECT requires a number of URLs that will enable seamless communication between agents and our cloud portal. This document will help you to list all the URLs and ports required to be exempted for unrestricted access such that the Agents could communicate correctly with the cloud services.
| Destination | URL | Purpose |
|---|---|---|
| The Platform | https://portal.appseconnect.com | The main portal is where the integration developer does every configuration. iPaaS Platform. |
| The API | https://admin.appseconnect.com | The API stack is used to download User info and custom metadata. |
| Storage | https://appsdrive.blob.core.windows.net/ https://appsdrive.table.core.windows.net/ | Represents configuration store, where most of the configuration created in Platform is stored. |
| Storage | https://appsdatalake.blob.core.windows.net/ https://appsdatalake.table.core.windows.net/ | Represents transactional store, where all metadata related to sync is uploaded. |
| Service Bus | https://aec-prod.servicebus.windows.net | In Memory event hub, which tracks any important event raised on the agent. It also uses sb:\\ protocol to communicate |
| Service Bus | https://appseconnect.servicebus.windows.net | Hook for Service bus, required to execute real-time proxies. Service Bus represents a brokered service communication architecture. It also uses sb:\\ protocol to communicate |
| SignalR Server | https://services.appseconnect.com | Represents the real-time communication channel for web sockets. The Agent connects to the socket using wss:\\ protocol to the service. |
| Document Database | https://aecprod.documents.azure.com/ | APPSeCONNECT document database, which is used by the new ProcessFlow engine. |
| Realtime Proxy URL | https://(subdomain).appseconnectapi.com/ | The real-time communication channel is created to post messages to the agent in real-time. This URL needs to be configured on the application webhook such that the data could be passed in the URL. The subdomain here is configured by the customer. |
Triggered ProcessFlows
It is highly recommended to use Proxy to configure real-time configurations, but if you still require to communicate using a local server’s public IP, you need to exempt 80 ports of that machine, such that the local port could be correctly opened. The port and the URL could be configured in settings of the APPSeCONNECT agent or from Portal.
For proxy or API management, the URL will be in *.appseconnectapi.com format. The * is the subdomain chosen by the customer
Cloud Application Exemptions
If you are using our hosted agent to communicate between applications, some of the applications might not be open for public access, for example, SAP Business One Service Layer, Dynamics Business Central, etc. In such a case you need to exempt access to these Business Apps from our cloud agent.
To ensure our cloud agent can access your application directly, you need to ensure our agent URL: https://engine.appseconnect.com is exempted from the Firewall of your local server where your business application resides.
Our Cloud agent will use the gateway engine.appseconnect.com to call the line of business applications and hence you will receive inbound calls only from this URL.
Please ensure this server is exempted as well from the firewall to have your sync process access application data directly.
Ports For Exemption
In addition to these URLs, we also need local ports to be opened as follows:
- APPSeCONNECT Agent opens a listener at Port: 59050
- APPSeCONNECT Service opens a listener at Port: 59051
These ports need to be exempted from the firewall such that the Inter-process communication between the service and the local agent application could be made.
All communications are through HTTPS (256 BIT Encrypted) only.
